PTZ CAM10A
10X Optical Conference Camera
PTZ CAM10A 10X Optical Zoom Conference Camera, 1080p Full hd Wide-Angle Webcam with Remote Control,USB PTZ Camera for Video conferences, Recording and Streaming.








10X optical zoom

10X optical zoom with 2.38 mega pixel HD-SDI, HDMI USB Video Output








HDMI USB 3G-SDI 3 Outputs Simultaneous








Accurate, smooth and silent ptz movement


Along with 350 degree pan& 90 degree tilt rotation at adjustable speed and fast & accurate focus to capture any view in conferencing space.








Multiple Installations

Support multiple mount way: available to install on desk, monitor, wall, tripod or up-side down in-ceiling.








Compatible Software

Compatible with all video conference software, like Zoom, Skype, Go TO Meeting; Webex, MS Team, and Bluejeans.



Product display
Product specification
Product model
PTZ CAM10A
Camera
• Image Sensor:1/2.9 inch HD Color CMOS
• Effective Pixel:2.38 mega pixel(16:9) • Horizontal Resolution:1080P60/30/25, 1080i60/50, 720P 60/50 • Focal Length:F=5.5mm(wide)--50(tele) • Signal Standard:NTCS/PAL • Zoom:10x zoom • Horizontal viewing angle: 69.7° at the near end, 7.56° at the far end. • Gain Control:Auto/Manual • SNR Ratio:≥50dB • Preset Position:IR remote supports 10 presets, PELCO Control Protocol supports 64 presets


• Pan/Tilt Movement Range: Pan:±175°(Max speed 80°/S); Tilt:-35°--+55°(Max speed 60°/s) • Control Terminal:RS-232, RS-485 • Control Protocol:VISCA, PELCO-D, PELCO-P(RS-232, RS-485) • Video output:USB, SDI, HDMI • Noise Reduction:2D/3D • Work Temperature:-10°--50° • Work Humidity:-20°--60° • Baud Rate:38400/9600bps • Address Set:1-64
• Weight:1.5kg/2.85(before/afyer packing) • Decoder:Built-in • Installation:Support desktop, Tripod, Wall mount and Ceiling mount • Video Compression Format:YUV, MJPEG, H.264 • Accessories:DC 12V power adaptor, IR remote control, Manu, USB 2.0 cable, Ceiling brackets & screws • Size:182*182*182mm/257*220*210(before/after packing)
