PTZ CAM20U
20X Optical Conference Camera
PTZ CAM20U 20X Optical Zoom Conference Camera, 1080p Full hd Wide-Angle Webcam with Remote Control,USB PTZ Camera for Video conferences, Recording and Streaming.








20x optical zoom

20x optical zoom，Sleek and intelligent design，Plug & Play USB Connectivity.








Super far field of view

Horizontal viewing angle: 63.2° at the near end, 3.54° at the far end.








Accurate, smooth and silent ptz movement


Along with 350 degree pan& 90 degree tilt rotation at adjustable speed and fast & accurate focus to capture any view in conferencing space.








Multiple Installations

Support multiple mount way: available to install on desk, monitor, wall, tripod or up-side down in-ceiling.








Compatible Software

Compatible with all video conference software, like Zoom, Skype, Go TO Meeting; Webex, MS Team, and Bluejeans.



Product display
Product specification
Product model
PTZ CAM20U
Camera
• Image Sensor：1/3 inch HD Color CMOS
• Effective pixel：2.1 mega pixel(16:9) • Horizontal Resolution：1080P30/25, 720P30/25 • Signal standard：NTSC/PAL • Zoom：20x optical zoom • Minimum luminance：0.5Lux at F2.0 • Focal length：f=5.0mm~50.0mm F1.8(W)~2.1(T) • Horizontal Angle：Near-end 55.5°~Far-end 3.0° • Gain control：Auto • Focus：Auto • White balance：Auto • SNR ratio：≥50dB


• Shutter speed：8 to 1/10000s (auto)
• Preset position：IR remote control supports 9 presets,PELCO Protocol supports 256 presets • Pan/Tilt movement range：
Pan: 175°(max speed 80°/S), Tilt: 35°~55°(max speed 60°/S) • Control terminal：USB, RS-232, RS485 • Control Protocol：VISCA, PELCO-D, PELCO-P (RS-232, RS485) • Video output：USB • Video Compression Format：YUV, MJPG, H.264 • Noise Reduction：2D/3D • Work temperature：-10°C-~50°C • Storage temperature：-20°C~60°C
• Baud rate：38400/9600bps
• Decoder：Built-in • Address set：1~256 • Installation：Support desktop, Tripod, Wall mount and Ceiling mount • Power supply：DC12V/ 2A • Power consumption：12 W • Net weight/Gross weight：1.5kg/2.85g • Dimension(LXWXH)：260*175*180 mm /296*255*218mm (before / after packing) • Accessories：DC 12V Power adaptor, IR remote control, Manual, USB2.0 cable, Ceiling brackets & screws.
