PTZ CAM4K comes with an Ultra-HD imaging systen,really delivers brilliantly sharp video, outstanding color, and exceptional optical accuracy at resolutions up to 4k.
This camera adopts 1/2.7 inch HD color CMOS, 8.29 effective mage pixel, 138° super-wide field of view, to emphasize faces and render natural-looking skin tones, even in dim or backlit conditions. PTZ CAM4K meets with the application for Ultra HD recording and streaming, video conferencing, and broadcasting thats supports USB cameras.
Pan:-175 to +175 degree, Tilt:+55degree，Zoom:Fixed focus. 8.29mega pixe(16:9)
138 °Field of view
138 °wide field of view with no video distortion(Pan:±175°(max speed 80°/s),Tilt: -35°~+55°).
Accurate, smooth and silent ptz movement
Along with 350 degree pan& 90 degree tilt rotation at adjustable speed and fast & accurate focus to capture any view in conferencing space.
Support multiple mount way: available to install on desk, monitor, wall, tripod or up-side down in-ceiling.
Compatible with all video conference software, like Zoom, Skype, Go TO Meeting; Webex, MS Team, and Bluejeans.
• Image Sensor:1/2.7 inch HD Color CMOS
• Effective pixel:8.29 mega pixel(16:9)
• Signal standard:NTSC/PAL
• Lens:fixed focus 2.1mm wide angle lens
• SNR Ratio:≥50 dB
• Field of view:fixed focus, 138°
• Control terminal:RS-232,RS485
• Pan movement range:Pan:±175°(max speed 80°/s)
• Tilt movement range:Tilt:-35°~+55°(max speed 60°/s)
• Preset position:IR remote controller supports 9 presets,PELCO Control protocol supports 256 presets.
• Control protocol:VISCA, PELCO-D, PELCO- P(RS-232, RS485)
• HD video output:USB
• Work temperature:-10°~50°
• Work humidity:-20°~60°
• Baud rate:38400/9600bps
• Address set:1~256
• nstallation:support desktop,Tripod, wall mount and ceilling mount
• Power supply:DC12V/2A
• Weight:1.5kg/2.85kg(before/after packing)
• Size:182*182*182mm/262*233*220mm(before/after packing)
• Accessories:DC12V power adaptor, IR remote control, ceilling brackets & screws, manual, USB cable
